RD4 Telescopic Bollard

The 'original' telescopic driveway security post, designed and built for all residential access control security applications.

Raised and lowered into position using the unique 'turn & lift' method, and inserted with the 'Award Winning' high-security 10 pin push-button top lock, this superb lightweight telescopic bollard has proven itself to be one of the most effective retractable bollards to use on a private driveway when you're looking to protect your vehicles and property.

Specification

• 76mm diameter.
• 580mm raised height.
• 7kg pull up weight.
• 4mm steel gauge.
• High-security 10 pin push button top lock.
• 2 keys supplied (per bollard).
• RD4 telescopic bollard data sheet (PDF)

Guarantees

• 30-day returns or exchange.
• 1-year manufacturer's guarantee.
• Accredited to the 'Secured by Design' Police initiative.
• Manufactured to meet the 'Sold Secure' industry standard.

Overview

• Designed for all residential high-security, access control, car parking applications.
• High-security protection on your driveway for a saloon and estate type vehicle.
• Inserted with the 'Award Winning' 10 pin push-button top lock.

• Unique key & lock number allocated to your bollard(s).
• Keys can't be copied or the lock picked or drilled.
• Stainless steel cover plate to protect the lock.
• Easily raised and lowered in seconds.
• Fixed stainless steel lifting handle.
• Lockable in the raised and lowered position.
• Heavy-duty hinged lid to protect the bollard when lowered.
• Fully serviceable and replaceable components.

Manufacture

• Represents the very best of British design and engineering.
• Hand-built to order here in the UK.
• 810mm x 120mm x 3.6mm galvanized steel outer casing.
• Mild steel components manufactured to BS1440.
• All parts hot-dipped galvanized to BS EN ISO 1461 (2009).
• 20kg overall product weight.

Maintenance

• To help keep the 10pin top-lock in tip-top condition, we recommend the regular use of our specially formulated lubricating lock oil.
• This will ensure the smooth operation of your bollard for many years to come.
• Keep the base of the bollard clear of dirt, debris, and leaves, etc.
• Cleaning the retractable inner bollard.

Ground Conditions

• Suitable for flat or sloping ground and any hard or soft surface.
• Not recommended for sites prone to regular deep water flooding.
• Areas with a high water table may experience slower water dispersion.

DIY Installation

• Excavation depth: 960mm (includes 150mm for drainage).
• Tools required - CAT scanner, stone cutting saw, concrete breaker, post borer, long-arm graft, shovel, spirit level, trowel, hand tools, and a wheelbarrow.
• Materials required - 20mm shingle, 10mm shingle, ballast, sharp sand, rapid set cement, cement dye (optional), mortar plasticiser, and water.
• Approx time to install - 1-2 hours (per bollard).
• DIY installation guide (PDF)

Our Installation Service

• Price applies to the installation of a single bollard and includes the all-important cable avoidance scan (CAT scan), road tolls, fuel, alignment, excavation, installation, materials, surface reinstatement, and spoil removal from the site.
• Your installer's vehicle is fully equipped and will carry the necessary tools to complete the work. Your installer will also provide their own electricity and water supply.
• Discounts are available for multiple installations at the same location (see our 'Buy More - Save More' rates above).
• More details about our installation service

Ordering your installation(s)

• To have one of our experienced, fully insured operatives install your bollard(s) simply 'ADD INSTALLATION' to your order.
• You will then be allocated an installer, and your goods will be manufactured and delivered to you within the estimated delivery date shown above.
• Once you receive your goods, simply contact your allocated installer to arrange an installation date that we guarantee will be carried out within the estimated installation date shown above.
• The postcode areas we cover
